Clamp Assemblies Standard Series Size 3 Ø22mm Polyamide W10 Insert, Hex Head Bolt Weld Plate, short

SP-322-PA-H-ES-AS-M-W10

STAUFF Material No. 1110008955

View Technical details

Quantity in pieces

Check pricing and stock availability

List price

This material is only available on request. Add to the enquiry list

Add to Enquiry List

You have a regular demand for pipework equipment and hydraulic components and you are looking for individual pricing for our product range, please contact STAUFF.

Technical details
Bill of materials

STAUFF Online Page-Flip Catalogue

Navigate and search content, forward via email, print, and download in PDF format

Open STAUFF Online Page-Flip Catalogue in New Tab

STAUFF product catalogue

Download catalog

Standard

DIN 3015-1

STAUFF Series

Standard Series

STAUFF Size

Group 3 (DIN 3015 Size 3)

Type of Installation

Single Weld Plate

Installation of Pipes

Installation of Hoses

yes

Installation of Cables

yes

fixed installation of line

sliding installation of line

yes

Vibration Reducing

low

Tension Clearance

Inside Surface

Smooth

for Diameter (mm)

Material (Clamp Body)

PA Polyamide

Material (Weld Plate)

Steel, Phosphated

Material (Bolt)

Steel, Zinc-Nickel coated

Packaging unit

25 pieces

The product shown above is a kit consisting of several individual components. It is not always possible to order all individual components of a kit separately in the STAUFF online shop. Below you will find an overview of all purchasable individual components of the kit. Please note: If you order these components individually, please make sure to check that the kit is complete to ensure that it functions properly.
